Specifications

• ENGINE

  add remove
  • Engine Type:
    Horizontally Opposed
  • Cylinders:
    6
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    118
  • Torque (Ft Lbs):
    125
  • Torque (Nm):
    169.5
  • Cooling:
    Liquid
  • Valves:
    12
  • Valves Per Cylinder:
    2
  • Valve Configuration:
    SOHC
  • Bore (in):
    2.92
  • Stroke (in):
    2.8
  • Displacement (cc):
    1832
  • Carburetion Type:
    Fuel Injected
  • Carburetion Brand:
    Keihin
  • Turbocharged:
    No
  • Supercharged:
    No
  • Compression Ratio:
    9.8:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    5
  • Primary Drive (Rear Wheel):
    Shaft
  • Overdrive:
    Yes
  • Reverse:
    Yes
• TECHNICAL SPECIFICATIONS

  add remove
  • Wheelbase (in):
    66.5
  • Fuel Capacity (gal):
    6.6
  • GVWR (lbs):
    1180
  • Storage Capacity (gal):
    33.4
  • Wet Weight (lbs):
    904
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Suspension Size (in):
    1.8
  • Front Travel (in):
    4.8
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Single Sided Swing Arm
  • Rear Suspension Material:
    Aluminum
  • Rear Travel (in):
    4.1
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Brand Name:
    Pro Arm
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Front Tire (Full Spec):
    130/70 R18
  • Rear Tire (Full Spec):
    180/60 R16
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    11.7
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    12.4
  • Anti-Lock Brakes:
    Not Available
  • Linked Brake System Front to Rear:
    Standard
